FODAY F22 DIESEL PICKUP Specification

Model Type

1030N3

1030N3Y

1030N3A

1030N3YA

Length/width/height (mm)

5330/1870/1864

Wheel base (mm)

3,100

Curb Mass(kg)

1,885

1,930

1,885

1,915

Gross Weight(kg)

2835

2880

2725

2780

front wheel base (mm)

1,580

rear wheel base (mm)

1,580

angle of approach/departure

26.7/27.1°

Ground clearance (mm)

217

QTY of Seats

5

Fuel tank capacity (L)

72L

Tire model

245/70R17

Engine model

YUNNEI 2.0T D20TICD

Engine type

common rail direct injection

Drive mode

2WD

4WD

2WD

4WD

Emission level

China 4

Air displacement (cc)

1,910

compress ratio

16：1

Maximum power (kW/rpm)

110/4000

Maximum torque (N.m/rpm)

200/3000

320/4000

Maximum torque (N.m/rpm)

350/2800

Fuel specification

0# diesel

Comprehensive fuel consumption

7.8

Transmission type

6-speed munual

gearbox

6-speed automatic gearbox

Suspension system (front/rear)

Double Wishbone Independent Suspension/leaf spring

Braking system

Front Ventilated Disc/rear drum

Steering system

Hydraulic power steering

FODAY F22 CBU equipment

integrated headlight

●

Steering auxiliary light of exterior rear-view mirror

●

follow me home-ceiling light

●

Front/rear high penetration foglight

●

Electricadjustingfunction of exterior rear-view mirror

●

High strength insulating glass

●

17-inch aluminum alloy wheel hub

●

full size spare wheel (steel rim)

●

Multi-function steering wheel

●

up-down adjustable steering wheel

●

Height adjustable seat belt-first row seat

●

Manually 4-way adjustable main driver's seat

●

Manually 4-way adjustable front passenger seat

●

co-driver side sunvisor

●

Anti-lock brake system (ABS)

●

Electronic brake force distribution

●

reversing image

●

Driver/front passenger seat dual airbag

●/●

Reminder of not fastening safety belt of driver seat

●

central remote

●

button start

●

Engine electronic anti-theft lock

●

three point seat belt at second row seat

●

Child safety lock

●

AC

●

One-button down for door electric window

●

Front/rear 12 V power interface

●

9-inch colorful touch screen

●

Bluetooth phone/music function

●

MP3/MP4/USB function interface

●

Speaker

●/8

FODAY F22 DIESEL PICKUP Specification

Model Type

1030N2

1030N2Y

1030N2A

1030N2YA

Length/width/height (mm)

5330/1870/1864

Wheel base (mm)

3,100

Curb Mass(kg)

1,885

1,910

1,885

1,910

Gross Weight(kg)

2825

2880

2825

2880

front wheel base (mm)

1,580

rear wheel base (mm)

1,580

angle of approach/departure

26.7/27.1°

Ground clearance (mm)

217

QTY of Seats

5

Fuel tank capacity (L)

72L

Tire model

245/70R17

Engine model

YUNNEI 2.0T D20TICE

Engine type

common rail direct injection

Drive mode

2WD

4WD

2WD

4WD

Emission level

China 5

Air displacement (cc)

1,910

compress ratio

16：1

Maximum power (kW/rpm)

110/4000

Maximum torque (N.m/rpm)

350/2800

Fuel specification

0# diesel

Comprehensive fuel consumption

7.8

Transmission type

6-speed munual gearbox

6-speed automatic gearbox

Suspension system (front/rear)

Double Wishbone Independent Suspension/leaf spring

Braking system

Front Ventilated Disc/rear drum

Steering system

Hydraulic power steering

FODAY F22 CBU equipment

integrated headlight

●

Steering auxiliary light of exterior rear-view mirror

●

follow me home-ceiling light

●

Front/rear high penetration foglight

●

Electricadjustingfunction of exterior rear-view mirror

●

High strength insulating glass

●

17-inch aluminum alloy wheel hub

●

full size spare wheel (steel rim)

●

Multi-function steering wheel

●

up-down adjustable steering wheel

●

Height adjustable seat belt-first row seat

●

Manually 4-way adjustable main driver's seat

●

Manually 4-way adjustable front passenger seat

●

co-driver side sunvisor

●

Anti-lock brake system (ABS)

●

Electronic brake force distribution

●

reversing image

●

Driver/front passenger seat dual airbag

●/●

Reminder of not fastening safety belt of driver seat

●

central remote

●

button start

●

Engine electronic anti-theft lock

●

three point seat belt at second row seat

●

Child safety lock

●

AC

●

One-button down for door electric window

●

Front/rear 12 V power interface

●

9-inch colorful touch screen

●

Bluetooth phone/music function

●

MP3/MP4/USB function interface

●

Speaker

●/8

●means with the device; "-" means without the device; "○" means optional device; this catalog is for reference only, and product specifications shall subject to actual vehicle;
