Vehicle configuration table

Language

CN

EN

Interior model

NFQ6480HEVR-H

NFQ6480HEVR-H

Energy type

增程式

Extende hybrid

Environmental protection standard

-

-

Length (mm)

4771mm

4771mm

cab wide body cab width

1870mm

1870mm

Height(mm)

1828mm

1828mm

Carriage size mm

-

-

wheelbase (mm)

2790

2790

tread (mm)

1580/1580

1580/1580

curb weight (kg)

2190

2190

Full load Max weightkg

2640

2640

Maximum speed (km/h)

120

120

CLTC pure battery range

160

160

Fast charge time (hours)

1.5h

1.5h

Slow charge time (hours)

AC 6.6kW 7h

AC 6.6kW 7h

Fuel consumption under minimum charge (L/100km)

7L/100km 以实际样车测试为准

7L/100km
The actual sample car test shall prevail

endurance mileage（km）Full gasoline and full charge

700km

700km

Control form

右舵

RHD

Vehicle category

豪华型

luxury

Body structure

5门6座SUV

5 DOOR 6SEAT SUV

Driver type

前置后驱

rear-drive

Body color

Sales type

出口

export

Basic configuration

Engine type

DAM15HE

DAM15HE

Engine Displacement (L)

1.5

1.5

Intake

自然吸气

naturally aspirated

Maximum engine power (kW)

71.5

71.5

Maximum engine torque (N.m)

140

140

Fuel type

汽油

gasoline

Tank capacity (L)

42

42

Drive motor type

永磁

Permanent magnet

Number of driving motors

单电机

Single motor

Motor layout

后置

postposition

Maximum power of drive motor (kW)

120

120

Maximum torque of drive motor (N.m)

320

320

Battery type

磷酸铁锂电池

lithium iron phosphate battery

Battery brand

弗迪

弗迪

Battery energy (KWh)

44.9

44.9

Battery cooling system

液冷

liquid cooling

Transmission type

—

—

Transmission gear

—

—

Ventilated disc front brake

●

●

Disc type rear brake

●

●

Brake drum type rear brake

—

—

Double cross arm coil spring front suspension

●

●

Five-link helical spring rear suspension

●

●

Leaf spring rear suspension

—

—

Electrohydraulic power steering

●

●

Rack and pinion steering machine

●

●

Two-way adjustable steering wheel

●

●

Double circuit four-channel ABS

●

●

Electronic gas pedal

●

●

CAN bus

●

●

17 "aluminum alloy rims (12 silver panels)

—

—

17 "aluminum alloy rims (12 two-color panels)

●

●

17 "aluminum alloy rims (six silver panels)

—

—

265/65 R17

●

●

Tire pressure monitoring

●

●

Traffic recorder

●

●

Control and security configuration

ABS+EBD

●

●

ESC

—

—

Main pilot airbag

●

●

Passenger airbag

●

●

Front seat belt

●

●

The front seat belt height is adjustable

●

●

Seat belt not fastened alarm

●

●

Second row seat belt

●

●

Collapsible steering column

●

●

Car central control lock

●

●

Remote key

●

●

Keyless access to PEPS+ electronic theft prevention

●

●

Engine anti-theft

—

—

Child safety lock (rear door)

●

●

Astern image (360 degree image)

●

●

Automatic driving lock/flameout unlock

●

●

The doors unlock automatically after a collision

●

●

Electronic parking

●

●

Differential lock

—

—

Brake Override System (BOS)

—

—

Overspeed alarm

—

—

External configuration External configuration

Clip-proof electric sunroof

●

●

Power rearview mirror

●

●

Rear windshield heating function

-

-

Shark fin antenna (including GPS navigation)

●

●

Common antenna (including GPS navigation)

—

—

Ordinary antenna

—

—

Boneless wipers

●

●

Rear wiper

●

●

Welcome pedal

●

●

Boarding step

●

●

Hood air strut

●

●

Luggage rack

●

●

Roll cage

—

—

spoiler

●

●

Door wipe strip

●

●

Koho

—

—

Dahou Bao (different colors)

—

—

Big back (same color black)

—

—

Box treasure (black, optional)

—

—

Van trunk cover

—

—

Chrome trim (front grille, door wipe, rear handle)

—

—

Internal configuration

Leather multi-functional steering wheel

●

●

Ordinary steering wheel

—

—

Glasses case

●

●

A-post handrail

●

●

Side door power window

●

●

Makeup mirror with front visor

●

●

ashtray

●

●

Cigarette lighter

●

●

Car 12V power supply

●

●

Internal rearview mirror anti-glare (manual)

●

●

Trunk attaching hook

●

●

Cup holder

●

●

Glove box

●

●

Seat configuration

Imitation leather

●

●

Driver seat adjustment mode

手动四向

4way manual

Co-pilot adjustment mode

手动四向

4way manual

2nd-row  seats

●

●

Three rows of seats in a 50-50 ratio

●

●

Multimedia configuration

radio +USB+ rear view

●

●

Central touch screen

—

—

Conventional instrument

常规仪表

Conventional

12.3-inch Android display

●

●

Streaming rearview mirror

—

—

Mobile Internet

●

●

GPS navigation system

●

●

Bluetooth system

●

●

External audio interface (AUX/USB, etc.)

●

●

8 speakers

●

●

4 Loudspeakers

-

-

2 Speakers

—

—

Lighting arrangement

Headlamp type

●

●

Steering wheel electronic lock

●

●

Headlight height adjustable

●

●

Car lights off delay

●

●

Front fog lights (excluding daytime running lights)

●

●

Rear fog lamp

●

●

High brake light

●

●

External rearview mirror with side turn signal

●

●

Top light

●

●

Door lamp

●

●

air conditioner.

Electric air conditioner

●

●

Air conditioning function

cool/heat

cool/heat

rear A/C

●

●

External circulation air filter

●

●

Second row foot blower

●

●
