Vehicle configuration table

Language

CN

EN

Interior model

NFQ1030HEVR-H

NFQ1030HEVR-H

Energy type

增程式

Extende hybrid

Environmental protection standard

-

-

Length (mm)

5330

5330

cab wide body cab width

1870

1870

Height(mm)

1864

1864

Carriage size mm

-

-

wheelbase (mm)

3100

3100

tread (mm)

1580/1580

1580/1580

curb weight (kg)

2145

2145

Full load Max weightkg

2970

2970

Maximum speed (km/h)

120

120

CLTC pure battery range

160

160

Fast charge time (hours)

1.5h

1.5h

Slow charge time (hours)

AC 6.6kW 7h

AC 6.6kW 7h

Fuel consumption under minimum charge (L/100km)

endurance mileage（km）Full gasoline and full charge

—

—

Control form

右舵

RHD

Vehicle category

豪华型

luxury

Body form

DOUBLE CABIN

DOUBLE CABIN

Body structure

Driver type

前置后驱(4*2)

rear-drive

Body color

Sales type

出口

export

Basic configuration

Engine type

DAM15HE

DAM15HE

Engine Displacement (L)

1.5

1.5

Intake

自然吸气

naturally aspirated

Maximum engine power (kW)

71.5

71.5

Maximum engine torque (N.m)

140

140

Fuel type

汽油

gasoline

Tank capacity (L)

42

42

Drive motor type

永磁

Permanent magnet

Number of driving motors

单电机

Single motor

Motor layout

后置

postposition

Maximum power of drive motor (kW)

120

120

Maximum torque of drive motor (N.m)

320

320

Battery type

磷酸铁锂电池

lithium iron phosphate battery

Battery brand

弗迪

弗迪

Battery energy (KWh)

44.9

44.9

Battery cooling system

液冷

liquid cooling

Transmission type

—

—

Transmission gear

—

—

Ventilated disc front brake

●

●

Disc type rear brake

●

●

Brake drum type rear brake

—

—

Double cross arm coil spring front suspension

●

●

Five-link helical spring rear suspension

—

—

Leaf spring rear suspension

●

●

Electrohydraulic power steering

●

●

Rack and pinion steering machine

●

●

Two-way adjustable steering wheel

●

●

Double circuit four-channel ABS

●

●

Electronic gas pedal

●

●

CAN bus

●

●

17 "aluminum alloy rims (12 silver panels)

—

—

17 "aluminum alloy rims (12 two-color panels)

●

●

17 "aluminum alloy rims (six silver panels)

—

—

265/65 R17

●

●

Full size spare tire (aluminum wheels)

—

—

Full size spare tire (steel hub)

—

—

Tire pressure monitoring

—

—

Traffic recorder

—

—

●

●

Control and security configuration

ABS+EBD

●

●

ESC

—

—

Main pilot airbag

●

●

Passenger airbag

●

●

Front seat belt

●

●

The front seat belt height is adjustable

●

●

Seat belt not fastened alarm

●

●

Second row seat belt

●

●

Collapsible steering column

●

●

Car central control lock

●

●

Remote key

●

●

Keyless access to PEPS+ electronic theft prevention

●

●

Engine anti-theft

—

—

Child safety lock (rear door)

●

●

Astern image

●

●

Automatic driving lock/flameout unlock

●

●

The doors unlock automatically after a collision

●

●

Electronic parking

●

●

Differential lock

—

—

Brake Override System (BOS)

—

—

Overspeed alarm

—

—

External configuration External configuration

Power rearview mirror

●

●

Rear windshield heating function

-

-

Shark fin antenna (including GPS navigation)

-

-

Common antenna (including GPS navigation)

—

—

Ordinary antenna

●

●

Boneless wipers

●

●

Rear wiper

-

-

Welcome pedal

●

●

Boarding step

●

●

Hood air strut

●

●

Luggage rack

—

—

Roll cage

●

●

spoiler

—

—

Door wipe strip

●

●

Koho

—

—

Dahou Bao (different colors)

●

●

Box treasure (black, optional)

—

—

Van trunk cover

—

—

Internal configuration

Leather multi-functional steering wheel

●

●

Ordinary steering wheel

—

—

Glasses case

—

—

A-post handrail

●

●

Side door power window

●

●

Makeup mirror with front visor

●

●

ashtray

●

●

Cigarette lighter

●

●

Car 12V power supply

●

●

Internal rearview mirror anti-glare (manual)

●

●

Instrument car computer display

●

●

Trunk attaching hook

—

—

Cup holder

●

●

Glove box

●

●

Seat configuration

Imitation leather

●

●

Driver seat adjustment mode

手动四向

4way manual

Co-pilot adjustment mode

手动四向

4way manual

—

—

2nd-row electric business seats

—

—

Three rows of seats in a 50-50 ratio

—

—

Multimedia configuration

radio +USB+ rear view

●

●

Central touch screen

—

—

12.3-inch Android display

●

●

Streaming rearview mirror

—

—

Mobile Internet

●

●

GPS navigation system

●

●

Bluetooth system

●

●

External audio interface (AUX/USB, etc.)

●

●

8 speakers

●

●

4 Loudspeakers

-

-

2 Speakers

—

—

Lighting arrangement

Headlamp type

LED

LED

Steering wheel electronic lock

●

●

Headlight height adjustable

●

●

Car lights off delay

●

●

Front fog lights (excluding daytime running lights)

●

●

Rear fog lamp

●

●

High brake light

—

—

External rearview mirror with side turn signal

●

●

Top light

●

●

Door lamp

●

●

air conditioner.

Electric air conditioner

●

●

Air conditioning function

cool/heat

cool/heat

rear A/C

—

—

External circulation air filter

●

●

Second row foot blower

●

●
