CS01EV model configuration parameter

configuration parameter

practical

all--round

Premium

Configuration code

LBA7004AABEV S

LBA7004AABEVJ

LBA7004AABEVZ

Vehicle parameters

car body structure

Carrying type

Carrying type

Carrying type

Length,width and height (mm)

3162*1498*1585

3162*1498*1585

3162 1498*1585

Wheelbase (mm)

2050

2050

2050

Front--rear wheel pitch (mm)

1290/1290

1290/1290

1290/1290

Minimum ground clearance (mm)

135

135

135

Minimum turning radius (mm)

4.25

4.25

4.25

Range range(km)

170

170

170

Preparation mass (kg)

740

740

740

gross mass

1040

1040

1040

Vehicle warranty

Three years or 100,000 km

Three years or 100,000 km

Three years or 100,000 km

Battery and motor parameters

Power battery type

Lithium--ion battery

Lithium--ion battery

Lithium--ion battery

Power battery capacity (kW--h)

13.82

13.82

13.82

Charging voltage(V)

220

220

220

Charging time (hours)

6.5

6.5

6.5

Battery heating and intelligent thermal insulation

●

●

●

Battery warranty

8 years or 120,000 km

8 years or 120,000km

8 years or 120,000km

Type of motor

Permanent magnet synchronous motor

Permanent magnet synchronous motor

Permanent magnet synchronous motor

Brake energy recovery

●

●

●

Maximum motor power (kW)

20

20

20

Maximum torque (N--m)

85

85

85

Top vehicle speed (km--h)

≥100

≥100

≥100

chassis system

Electric vehicle single-speed transmission

●

●

●

Transmission type

Fixed tooth ratio gearbox

Fixed tooth ratio gearbox

Fixed tooth ratio gearbox

Drive form

Rear rear drive

Rear rear drive

Rear rear drive

Brake type

Front disc rear drum type

Front disc rear drum type

Front disc rear drum type

forward mounting

Front McPherson independent suspension

Front McPherson independent suspension

Front McPherson independent suspension

The rear suspension

Three--link--type nonindependent suspension

Three--link--type nonindependent suspension

Three--link--type nonindependent suspension

Shift form

Knob type

Knob type

Knob type

Brake priority system

●

●

●

tyre size

155/65 R13

155/65 R13

155/65 R13

Wheel material

steel rim

steel rim

steel rim

Fashion appearance

Lens headlights

Ordinary halogen headlights

Lens headlights

Lens headlights

Headlights are highly adjusted

●

●

●

Halogen taillight

●

●

●

After the fog lamp

●

●

●

LED daytime running lights

--

●

●

High brake light

●

●

●

External rear sharp (same color)

●

●

●

Open the handle outside

black

homochromy

homochromy

Bar antenna

●

●

●

Two--color hub cover

--

●

●

Monochromatic hub cover

--

--

--

Column B/C column black film

--

●

●

Door decoration

--

●

●

Side circumference icon

--

●

●

Two--color body

--

●

●

Exquisite interior

Knob--type electronic shift mechanism

●

●

●

Combination instrument

Monochromatic instrument

●(7 inches)

●(10.25--inch)

reading lights

●

●

●

Main driving road sun board

●

●(With a makeup mirror)

●(With a makeup mirror)

Internal rearviewmirror

●

●

●

copilot ceiling handle

●

●

●

Comfortable and convenient

Remote control key +central control lock

●

●

●

Electric window

●

●

●

Electric external rearview mirror

--

--

●

Multi-functional steering wheel

--

--

●

Electric power steering system (EPS)

●

●

●

The ramp auxiliary

●

●

●

Economy-movement patterns

●

●

●

air-conditioning

Heating and cooling air conditioning

Heating and cooling air conditioning

Heating and cooling air conditioning

Seat fabric

textile

textile

textile

Main driving seat

four-way control

four-way control

four-way control

The passenger seat

four-way control

four-way control

Four to byte

Rear seat

Conjoined,foldable

Conjoined,foldable

Conjoined,foldable

insurance

Front/rear radar

--

--

●

T-BOX

●

●

●

EDR

●

●

●

ABS

●

●

●

EBD

●

●

●

Collision is automatically unlocked

●

●

●

Automatically lock the car

●

●

●

The door was not warned

●

●

●

End door escape switch

●

●

●

Rear row ISOFIX child safety seat interface

●

●

●

Front row three-point seat belt

●

●

●

Rear three-point seat belt

●

●

●

The main driving seat belt does not wearing an alarm

●

●

●

Low-speed pedestrian warning system

●

●

●

Tire pressure monitoring

●

●

●

Intelligent entertainment

The USB/type-C interface

Two

Two

large-size screen monitors

●7 inches

●10.25 inches

Reversing camera

--

●

●

Intelligent voice interactioninteraction

--

--

●

Bluetooth

--

●

●

Mobile phone Internet-mapping

--

●

●

loudspeaker

Double speaker

Double speaker

Double speaker

360-degree panoramic imaging

other

Body color

white,green,

powder,gray

On white under green,On white under powder,

On white under gray, On black under white

Attachment with the car

Triangle warning signs,reflective vest,tow hooks

Description: ● Standard configuration； O Optional configuration； -- without this configuration
